BRAND	Loreme
Product	IPL 144L/C
Description	Power Network Analyzer
Internal code	IMP3412016
Weight	1
Custom code	90 30 89
Technical specification	ALSTOM version Mounting - IPL144 recessed, housing 144 x 72 mm Measurements - DC measurement: voltage, current, power - AV measurement: voltage, current, frequency, cos phi - active, reactive, apparent power - active energy consumed and generated - inductive and capacitive reactive energy - balanced, unbalanced three-phase network, with or without neutral - configurable IT and TP report Inputs - 3 voltage inputs - 0 to 125 Vac, +/- 175 Vdc and 0 to 500 Vac, +/- 700 Vdc - 3 current inputs - 0 to 1 Aac, +/- 1 Adc or - 0 to 5 Aac, +/- 5 Adc, set at command - frequency: 40 Hz to 400 Hz use: * Voltage: 0... 500Vac * Current: 0... 5Aac Display - IPL144L: 3 7-digit 7-segment LED displays Power supply 80 to 265 Vac/dc Isolation - 1500 Vac power/inputs Setting - USB connection (cord supplied separately) - 9-point D-sub connector on the back - Connection of the 3 intensities on threaded rods SLOT communication - type RS485 2-wire, Modbus protocol on slot #8

Please Contact Us to Order to offer competitive prices and delivery time for Loreme - IPL 144L/C Power Network Analyzer number, also you may ask some other model number is well. We can offer competitive price, and delivery time with wide products distribution network in Slovakia Industrial products Market.
