Buy CTD1X1005AXXX from Carlo Gavazzi in Slovakia

BRAND	Carlo Gavazzi
Product	CTD1X1005AXXX
Description	Current Transformer
Internal code	IMP241829
Weight	1
Technical specification	AC Current Transformer (max 23mm φ cable) Type CTD-1X • Cable and bus-bar type current transformer • 0.5 class, currents from 50 to 300 A • Removable DIN-rail mounting holder • Removable panel fixing clips • 2 cable/bus-bar isolated fixing screws • Double screw terminals (up to 8-wire connections) • Sealable terminal block covers Product Description Ordering Key CTD-1X 100 5A XXX Cable/Bus-bar type current transformer with DIN-rail/bus- bar and panel mounting facility. Type Selection Primary current From 50 to 300A (Refer to Range Table) Rated primary currents from 50 A to 300 A. Secondary current 1A 5A Model Primary current Secondary current Option Optional fixing kit: CTD-kit Option XXX:none XTX: tropicalization InputSpecifications Operating frequency48 to 62 Hz Max. system voltage0.72 kV Rated insulation level3 kV/1 min. @ 50 Hz Insulation class E (max 75°C) Short-time current rating Ith Typical 100 In /1 s Idyn 2.5 Ith The short-timethermal current Ith is anyway limited by the cable/bus-bar size Extended current rating 120% Security factor (FS)≤ 5 (Class: 0.5, 1 and 3) General Specifications StandardsAccording to EN60044-1 Housing ABS, self-extinguishing: UL 94 V-0 Mounting DIN-rail bus-bar and panel mounting Standard accessoriesTwo terminal block screws. Two sealable terminal block covers. Two panel mounting fixing clips. One DIN rail adapter. Optional accessories Extended fixing kit CTD-kit: Six cable/bus-bar fixing screws. Six plastic caps for cable/bus-bar fixing screws. Two panel mounting fixing clips. Special features1 A secondary current, Tropicalization Working temperature -25°C to +60°C (-13°F to 140°F) (R.H. < 90% non condensing @ 40°C) Storage temperature-30°C to +70°C (-22°F to 158°F) (R.H. < 90% non condensing @ 40°C) ApprovalsCE, cUrus and CSA ConnectionScrew type Cable cross section area From 1.5 to 6 mm2 Min/Max screws tightening torque relevant to terminal block screws: From 1 to 2 Nm Max screws tightening torque relevant to the cable/bus-bar fixing screws: 0,3 Nm Protection degree IP00 IP20 (with sealable terminal block covers + wire termi nals) Cable diameterMax. 23 mm Bus-bar sizeMax. 20x5 mm WeightFrom 150 to 200 g Output Specifications Rated secondary current5 A or 1 A

Discover the superior quality and performance of the Carlo Gavazzi CTD1X1005AXXX with Impexron GMBH in Slovakia . Whether you are looking for reliability or efficiency, this product meets all your industrial needs.

The CTD1X1005AXXX is designed to provide optimal performance and durability in various applications. Known for its high-quality construction and innovative features, it is a preferred choice for professionals.

Key Features of CTD1X1005AXXX :

High Performance: Engineered to deliver exceptional results.
Durable Construction: Built with high-quality materials for long-lasting use.
Innovative Design: Incorporates the latest technology for enhanced efficiency.
Cost-Effective: Offers great value for money with competitive pricing.

At Impexron GMBH , we offer the CTD1X1005AXXX at competitive prices and with the fastest delivery times across Slovakia . Our expert team is ready to assist you with all your inquiries and provide tailored solutions to meet your specific needs.

Why Choose Impexron GMBH ?

Expert Assistance: Get help from our knowledgeable team for all your product-related questions.
Competitive Prices: We offer some of the best prices in the market.
Fast Delivery: Benefit from our efficient delivery network for quick turnaround times.
Customer Satisfaction: Our commitment to customer service ensures a great buying experience.

Get Your Quote Today! Ready to enhance your operations with the CTD1X1005AXXX ? Contact us now for a personalized quote. Fill out the form below or send us an email with your inquiry. Let us help you make a cost-effective, quality-driven choice for your business.

Important Notice: While we supply Carlo Gavazzi products, Impexron GMBH is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
