| BRAND | Carlo Gavazzi |
| Product | CTD12H10005AXXX |
| Description | Current Transformer |
| Internal code | IMP241813 |
| Weight | 1 |
| Technical specification | AC Solid-core Current Transformer Type CTD-12V/12H (max 53x125mm) • Bus-bar type solid-core current transformer • Accuracy class 0.5 • Current range from 1000 to 4000A • Up to 8 bus-bar fixing screws • Double screw terminals (up to 4-wire connections) • Sealable terminal block covers Product Description Ordering Key CTD-12V4000 5AXXX Solid-core current trans- former with bus-barmount- ing facility. Rated primarycurrentfrom 1000 to 4000A. Model Primary current Secondary current Option Type Selection Model CTD-12V:vertical mounting CTD-12H:horizontal mounting Primary current 1000 1500 2000 2500 3000 4000 Secondary current 5A Option XXX:none InputSpecifications Operating frequency50-60 Hz Max. system voltage0.72 kV Rated insulation level3 kV/1 min. @ 50 Hz Insulation class B (1000 to 4000A) Short-time current rating Ith Typical 100 In /1 s Idyn 2.5 Ith The short-timethermal current Ith is anyway limited by the cable/bus-bar size Security factor (FS)≤ 10 Working temperature-30°C to +40°C (-22°F to 104°F) (R.H. < 90% non condensing @ 40°C) Storage temperature -30°C to +70°C (-22°F to 158°F) (R.H. < 90% non condensing @ 40°C) Approvals CE Connection Screw type Cable cross section area From 1.5 to 4 mm2 Protection degreeIP20 Bus-bar size Max. 53x125 mm Weight < 1.3 Kg General Specifications Standards Accordingto EN60044-1 Housing Polycarbonate UL94 V2 Mounting Bus-bar mounting Standard accessories Two terminal block screws. Eight bus-bar fixing screws. Two sealable terminal block covers. Output Specifications Rated secondary current5 A Burden15 VA |
Please Contact Us to Order to offer competitive prices and delivery time for Carlo Gavazzi - CTD12H10005AXXX Current Transformer number, also you may ask some other model number is well. We can offer competitive price, and delivery time with wide products distribution network in Slovakia Industrial products Market.
WE SELL ONLY NEW AND ORIGINAL PRODUCTS!
Our company is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
