BRAND | Tecsis (WIKA Group) |
Product | 9021299 |
Description | Flush pressure transmitter |
Internal code | IMP4064474 |
Technical specification | S-11 ; 0 ... 1 bar; 4...20 mA, @ 10...30 V DC; Accuracy: 0.5% of span G 1 B flush diaphragm with O-ring Wetted parts: stainless steel Sealing: NBR; 4-pin L-plug DIN EN 175301-803, IP65 UB=1, 0V=2 Permissible medium temperature: -30 ... +100 °C (-22 ... +212 °F) Specifications according to data sheet: PE 81.02 Details: Pressure transmitter for general applications Model S-11 with flush diaphragm Specifications according to data sheet: PE 81.02 Power supply: DC 10 (14) ... 30 V Case: stainless steel Output signal: 4 ... 20 mA, 2-wire Measuring range: 0 ... 1 bar Process connection: G 1 B flush diaphragm with O-ring Wetted parts: stainless steel Accuracy: 0.5% of span Electrical connection: 4-pin L-plug DIN EN 175301-803, IP65 Permissible medium temperature: -30 ... +100 °C (-22 ... +212 °F) Power supply: 10...30 V DC pin assignment el. connection: UB=1, 0V=2 Test protocol: without test protocol Certificates: without Import documentation CIS-States: without |
Please Contact Us to Order to offer competitive prices and delivery time for Tecsis (WIKA Group) - 9021299 Flush pressure transmitter number, also you may ask some other model number is well. We can offer competitive price, and delivery time with wide products distribution network in Slovakia Industrial products Market.
WE SELL ONLY NEW AND ORIGINAL PRODUCTS!
Our company is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
