BRAND | Scherzinger |
Product | 3030-110-B-ZK-63-120 |
Internal code | IMP4182615 |
Custom code | 84136039 |
Technical specification | Explosion protection: 2014/34/EU - II 2G Ex h IIC Gb X//II 2D Ex h IIC Db X • Preferred direction of rotation: left (ccw), view of the pump shaft • Intake volume: 1.1 cm³/U • Safety valve: 0 - 8 bar • Connections: DIN ISO 228, G 1/4” • Permitted Pump inlet pressure: -0.9... 89 bar • Operating temperature range: -20 to 130°C Case material: 1.4404 • Gear material: PEEK mod. • Waves: 1.4571 • Bearing: PEEK mod. stat. Seals: PTFE • Shaft seal: • max. 0.65 Nm • Sm2Co17 magnets, encapsulated in 1.4404 with motor-side magnetic coupling bell • Motor standard: IEC 72-1 • Size: IEC63 • Design: IMB34 • Flange diameter: 120 mm • Shaft: 11x23 mm |
Please Contact Us to Order to offer competitive prices and delivery time for Scherzinger - 3030-110-B-ZK-63-120 number, also you may ask some other model number is well. We can offer competitive price, and delivery time with wide products distribution network in Slovakia Industrial products Market.
WE SELL ONLY NEW AND ORIGINAL PRODUCTS!
Our company is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
