BRAND | Vickers (Eaton) |
Product | PVH074R01AA10A25000000100010A |
Description | axial piston pump |
Internal code | IMP4642453 |
Technical specification | Luck volume: 73.7 cm³/U Drive shaft rotation direction: Clockwise rotation (right side suction connection, left side pressure connection) Front flange and driveshaft: 01 lock c (SAE j744-127-4) with 31.8 [1.25] diameter straight attached shaft (key included), 56.0 [2.20] shaft extension Main ports, size and location: AA - side ports; suction - 2,000 sae 4-thread split flange port, standard pressure series (code 61) with 1/2-13 UNC 2b threads; pressure - 1,000 sae port with 4 threads for split flange, standard pressure series (code 61) with 3/8-16 UNC 2b threads Leak oil port size and location: .750-16 UNF-2B SAE O-ring port - bottom (top connected port) Diagnostic pressure connection: without measurement connection |
Please Contact Us to Order to offer competitive prices and delivery time for Vickers (Eaton) - PVH074R01AA10A25000000100010A axial piston pump number, also you may ask some other model number is well. We can offer competitive price, and delivery time with wide products distribution network in Slovakia Industrial products Market.
WE SELL ONLY NEW AND ORIGINAL PRODUCTS!
Our company is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
